DC High Voltage (3 Core Cable)


Model Number: SSI 569 TC

Standard Number: IS 1554IS 649

The insulation material in a cable is used to isolate the conductor from one another and from ground, as well as provide the necessary mechanical strength. The fundamental requirement of the insulation in an electric cable is that it withstand the voltage imposed on it in the service.

Salient Features
DC Voltage : Up to 2 KV DC
Stations :  3 independent Stations
Voltage Control : Using Dimmer
Voltage Display : Using Analog Volt Meter
Cut Off : Using Tripping System on any short circuit
Delivery Time : 3 to 4 Weeks Packing : One Wooden Box

Description

 The insulation material in a cable is used to isolate the conductor from one another and from ground, as well as provide the necessary mechanical strength. The fundamental requirement of the insulation in an electric cable is that it withstand the voltage imposed on it in the service.. It is necessary that a evaluation of the condition on the insulation be made by imposing a higher voltage stress for a short duration.

The DC High Voltage tester provides ideal condition to test any cable for its capability to withstand high DC voltage

The Instrument consist of (for each station)

    Dimmer to increase / decrease the DC HV

     HT DC output points

     2 KV Voltmeter. (other voltages available on request)

     Tripping Circuit

     Cable connectors

     Water Bath (to be purchased separately)
